Good Heat Dissipation Wedge Wire Screen Panels For Water Process / Fluid Treatment

Good Heat Dissipation Wedge Wire Screen Panels For Water Process / Fluid Treatment

wedge wire filter elements

vibrating screen panels

Place of Origin:

Hebei,China

Brand Name:

Heng Yuan

Certification:

ISO9000

Model Number:

HY004

Contact Us

Request A Quote
Product Details
Material:
Stainless Steel
Grade:
304
Slot Size:
0.7mm
Dimension:
Diameter 1.3 M, Up To 3m, Request
Package:
Woden Box,Container
Product Description

Johnson Wedge Wire Screen Mesh Panel For Water Process & Fluid Treatment





Product Description:



Johnson Wedge Wire Screen Mesh Panel For Water Process & Fluid Treatment is welded by V wire and support rod.There is a fixed value slot between each v wire. The support rod can be round wire can also be a triangular or trapezoidal shape, wedge wire is triangular wire , the wedge shape wire make the gap opening one end small and the other end large, it is not easy to jam.This product is processed by advanced fusion welding technology, with high strength, rigidity and bearing capacity, which can be used to make rigid sieving filters of various shapes.The slot size is accurate and the filtering precision is high.It has the advantages of strong structure, high ventilation efficiency, good heat dissipation, high temperature resistance, corrosion resistance, good mechanical properties, long service life, safe and reliable.



Specification:


Material Stainless steel
Grade 304
 Dimension 3 * 3 m, request
Slot Size 0.7 mm
Width  up tp 3000mm
Length  up to 3150mm
Type  screen plate
Wire size 2*3.5 mm
Support rod 3*4.6 mm
Wire shape V shape



Regular Specifications:



Material: stainless steel 302, 304, 316, 304L, 316L or low carbon galvanized

Slot: 0.1mm - 35mm

Discrepancy: + / - 0.05mm

Dimension: width up to 3000 mm

                    Length up to 3150mm

Good Heat Dissipation Wedge Wire Screen Panels For Water Process / Fluid Treatment 0Good Heat Dissipation Wedge Wire Screen Panels For Water Process / Fluid Treatment 1

Special specification can be made according to your need.





Advantages:



Wedge wire and support rod adopt the international advanced continuity resistance welding technology automation mine screen mesh welding production equipment, sieve seam even, stable welding quality, wear-resisting, long service life and has a high strength, stiffness and bearing capacity, can make various shapes of the rigid screening filter device. And the screen seam is v - shaped, easy to leak, not easy to plug.



Industry:



Products are mainly used for screening filter coal mine, coal products, such as iron ore, sandstone can also be used for food, oil, water and other solid liquid filter, mainly used in coal mine, coal washing, food, is a manufacturing and other industries, can also be used to decorate the breeding, etc.



Pictures:



Good Heat Dissipation Wedge Wire Screen Panels For Water Process / Fluid Treatment 2



Package:



Good Heat Dissipation Wedge Wire Screen Panels For Water Process / Fluid Treatment 3
