Stainless Steel 304 Johnson Wire Screen Od219mm Sand Control

Stainless Steel 304 Johnson Wire Screen Od219mm Sand Control

stainless steel 304 johnson wire screen

sand control johnson wire screen

ss 304 water well screen pipe

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
High Strength, Corrosion Resistance
Water Well Screen
8-5/8" (219mm)
5.8m To Fit Container
Wrapped Wire Size:
2*3.5mm, 2.2*3.5mm, 3*4.6mm, 3*5mm, 3*6mm
Surface Treatment:
End Connection:
Male/female Threaded, Welded Rings
Product Description

Water Well Screen Tubes Description:


Water Well Screen Tube has been a trusted name in the wire mesh screen industry for years. This product is made of high quality stainless steel or galvanized steel with a support rod size of ø3.8-6.0mm round wire. It is available in two lengths: 2.9/5.8m to fit a container, and has four different opening sizes: 0.5mm,0.63mm,0.76mm,1.0mm. It is designed with the latest full welding technology and all meshes are securely welded together to create a strong and durable wire mesh screen. Every package comes with a wooden box for easy storage and transportation.

Johnson Wire Screen is the perfect choice for any application where you need a strong, secure and long lasting wire mesh screen. It can be used for a variety of purposes, including industrial, agricultural, and residential applications. With its superior quality and durability, Johnson Wire Screen is the ideal choice for a wide range of projects.


Water Well Screen Tube Features:


  • Product Name: Water Well Screen Tube
  • End connection: Male/female Threaded, Welded Rings
  • Support rod size: ø3.8-6.0mm Round Wire
  • Material: Stainless Steel, Low Carbon Steel, Galvanized Steel
  • Diameter: 4" 6" 8" 10" 12" 14" 16"
  • Advantage: High Open Area


Water Well Screen Tube Applications:



Johnson Wire Screen, branded by Hengyuan and with model number 061201, is produced in HENGSHUI and certified by ISO, CIQ, CO, and FORM E. It is available for minimum order quantity of 1 piece and costs USD 20/piece. The packaging for Johnson Wire Screen is Wooden box, and the delivery time is 7 workdays. Payment Terms are T/T, and Supply Ability is 500m2/ day. It is characterized by high strength and corrosion resistance, and comes with Wooden Box package and high open area of 2.9/5.8m to fit container. Johnson Wire Screen is widely used in water wells for sand control.



Water Well Screen Tube Technical Parameters:


Property Description
Advantage High Open Area
Support rod size ø3.8-6.0mm Round Wire
Delivery time In One Week
Length 2.9/5.8m To Fit Container
Package Wooden Box
Features High Strength, Corrosion Resistance
End connection Male/female Threaded, Welded Rings
Diameter 4" 6" 8" 10" 12" 14" 16"
Surface Treatment Polished
Opening Size 0.5mm,0.63mm,0.76mm,1.0mm
