Name: Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Brand: Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd.
SKU: HY0222010
Price: 230 USD
Availability: InStock

Home > PRODUCTS > Johnson Wire Screen >

Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells

stainless steel wedge wire screen

johnson stainless steel screen

Place of Origin:

Hebei,China

Brand Name:

HengYuan

Certification:

ISO, CIQ, CQ

Model Number:

HY0222010

Request A Quote

Product Details

Name:

Vee-Shaped Wire Johnson Wire Wrapped Screen

Brand Name:

HengYuan

Material:

Stainless Steel 304, 316L, Duplex Steel 2205,2507 Etc.

Diameter:

4" 6" 8" 10" 12" 14" 16"

Technique:

Welding

Feature:

Non-clogging,anti-corrosion

Application:

Oil/gas/liquid Filtration

Slot:

0.5mm 0.63mm 0.75mm 1.0mm Etc

Slot 1.5mm Wedge CE Johnson Wire Screen Stainless Steel 304

Get Best Price

Video

Ss 304 316 V Wire Johnson Screen Pipe Wrapped Slotted For Filtration

Get Best Price

Video

Water Well Slot 1.0 Mm Johnson Wedge Wire Screens Stainless Steel

Get Best Price

Video

Cylinder Filter Johnson Wedge Wire Screens Foti Slot 0.5 Mm Stainless Steel

Get Best Price

86-318-7565918

hengyuan1@aphywire.com

86-318-7565919

Contact Now

Product Description

Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells

Product Specifications

Attribute	Value
Name	Vee-Shaped Wire Johnson Wire Wrapped Screen
Brand name	HengYuan
Material	Stainless Steel 304, 316L, Duplex steel 2205,2507 etc.
Diameter	4" 6" 8" 10" 12" 14" 16"
Technique	Welding
Feature	Non-clogging, anti-corrosion
Application	Oil/gas/liquid filtration
Slot	0.5mm 0.63mm 0.75mm 1.0mm etc

Product Description

The world's most advanced full wound welding process is adopted by the wrapped wire screen. The special stainless steel trapezoid (wedge-shaped) wire winding is welded on a group of longitudinal support rods arranged in a round arrangement, thus ensuring its strength and service life.

Due to the adoption of full program welding, not only the strict integrity of the product is ensured, but also the ideal gap size is formed. Compared with commonly used welding technology, the full welded wedged wire winding screen tube, filter pipe, water cap, water distributor, resin trap and sieve plate have the characteristics of smooth tube surface, no production edge angle, no burr, uniform gap and no grease leakage.

The wedge-shaped wire screen is widely used in oil, gas and water wells for sand prevention and its application in chemical industry, environmental protection, and other industries. It is the most widely used filter screen in all kinds of oil, water resources recycling, and resin collection.

Technical Specifications

Material	Stainless steel wire 304,302,304L,316,316L or galvanized steel wire
OD	1 Iinch,3 inch,4 inch,6inch,8 inch,10 inch,12 inch,14 inch,16 inch,18 inch,20 inch
The slot	0.1mm-45mm
The wire	2.0mm3.0mm ,3.0mm4.6mm,3.0mm*5.0mm
The rods	3.8mm/22,3.8mm/32,3.8mm/48,3.8mm/50
Styles of connection	Welding ring, threaded male/female coupling
Standard length	1000mm-5850mm
