Name: Johnson Type Rod Based Continuous Slot Water Wire Screen
Brand: Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd.
SKU: HY0222012
Price: 20 USD
Availability: InStock

Home > PRODUCTS > Johnson Wire Screen >

Johnson Type Rod Based Continuous Slot Water Wire Screen

Rod Based Water Wire Screen

Continuous Slot Water Wire Screen

Johnson Type Water Wire Screen

Place of Origin:

HENGSHUI

Brand Name:

Hengyuan

Certification:

ISO, CIQ, CO, FORM E

Model Number:

HY0222012

Request A Quote

Product Details

Name:

Johnson Type Rod Based Continuous Slot Water Wire Screen

Material:

Stainless Steel, Low Carbon Steel, Galvanized Steel

Diameter:

4" 6" 8" 10" 12" 14" 16"

Surface Treatment:

Polished

Application:

Water Wells For Sand Control

Mesh Type:

Full Welded

Length:

2.9/5.8m To Fit Container

Slot:

0.5mm 0.63mm 0.75mm 1.0mm Etc

Slot 1.5mm Wedge CE Johnson Wire Screen Stainless Steel 304

Get Best Price

Video

Ss 304 316 V Wire Johnson Screen Pipe Wrapped Slotted For Filtration

Get Best Price

Video

Water Well Slot 1.0 Mm Johnson Wedge Wire Screens Stainless Steel

Get Best Price

Video

Cylinder Filter Johnson Wedge Wire Screens Foti Slot 0.5 Mm Stainless Steel

Get Best Price

86-318-7565918

hengyuan1@aphywire.com

86-318-7565919

Contact Now

Product Description

Johnson Type Rod Based Continuous Slot Water Wire Screen

Product Specifications

Attribute	Value
Name	Johnson Type Rod Based Continuous Slot Water Wire Screen
Material	Stainless Steel, Low Carbon Steel, Galvanized Steel
Diameter	4" 6" 8" 10" 12" 14" 16"
Surface Treatment	Polished
Application	Water Wells For Sand Control
Mesh Type	Full Welded
Length	2.9/5.8m To Fit Container
Slot	0.5mm 0.63mm 0.75mm 1.0mm etc

Product Description

Johnson Type Rod Based Continuous Slot Water Wire Screen is a high quality wire mesh screen manufactured with stainless steel, low carbon steel or galvanized steel. It features high open area, high strength, corrosion resistance, and short delivery time.

The length of Johnson Wire Screen is between 2.9m and 5.8m, which is designed to fit a container perfectly. It is guaranteed to be delivered within one week, making it a perfect choice for urgent requirements.

Key Features

Product Name: Johnson Type Rod Based Continuous Slot Water Wire Screen
Name: Water Well Screen
End connection: Male/female Threaded, Welded Rings
Mesh Type: Full Welded
Advantage: High Open Area
Length: 2.9/5.8m To Fit Container
Special Feature: Wire Mesh Screen

Technical Parameters

Property	Details
Surface Treatment	Polished
Material	Stainless Steel, Low Carbon Steel, Galvanized Steel
Opening Size	0.5mm,0.63mm,0.76mm,1.0mm
Wrapped Wire size	23.5mm, 2.23.5mm, 34.6mm, 35mm, 3*6mm
Features	High Strength, Corrosion Resistance
Advantage	High Open Area
End connection	Male/female Threaded, Welded Rings
Diameter	4" 6" 8" 10" 12" 14" 16"
Length	2.9/5.8m To Fit Container
Delivery time	In One Week
